Mechanical Shearing Machine

Description

Mechanical shearing machine adopts advanced appliances (foot pedal and manual switch) with little noise and easy maintenance. Our mechanical guillotine shear, featuring attractive appearance and low energy consumption, uses integral steel welded structure that is simple and easy to operate. It can shear a large scale of materials and improve labor efficiency. Manufactured from raw materials of superior quality, our mechanical shearing machines are highly acclaimed for excellent quality and brilliant performance.

This metal plate shearing equipment is extensively applied in sheet metal processing plant, electrical appliance, motor, automobile manufacturing and other sheet metal processing plants. Applying the latest technology in the production process to ensure high productivity and durability, we are well renowned as one of the most preeminent mechanical shearing machine suppliers in China.

Features

1. Mechanical guillotine shear is another popular guillotine shear in metal fabricating industry. Its whole welded steel structure, light weight, compact construction, and small footprint make it versatile for various metal sheet shearing requirements.
2. This metal plate shearing equipment adopts integral welded steel plate structure, hydraulic upper transmission and vibration to eliminate stress. It is famous for high strength and good rigidity.
3. This mechanical shearing machine does shearing movement through the main oil cylinder, which can simplify the hydraulic system and make it run more stable. The top carrier swings like an arc around a fixed axis in the shearing process. Through the level effect, the machine affords small force, which can increase the service life of shearing blade as well as the shearing machine.
4. This mechanical guillotine shear is designed with compact structure that can adjust the amount of strokes of the top carrier and greatly improve work efficiency. Besides, It employs advanced integrated hydraulic system with good reliability.
5. The CNC system of this metal plate shearing equipment adopts display that is easy to operate.
When it comes to shearing, our selection of high quality shears is above the level of competitors. With our newly designed shearing machine lineup, all possible shearing jobs and requirements will be met by our machines, including swing beam shear, mechanical shearing machine, manual shearing machine, etc. YINLI is proud to offer our customers the most complete up-to-date shears available on the market today.

Notes

A shearing machine that combines all of your most-wanted elements is packed into one dynamic package: accuracy, high speed, low-energy cost, and flawless performance. This shearing machine is a staple in any production environment that relies on their shearing performance.
Give us the information of metal plate material, such as thickness, maximum width, and we will quote you the most suitable machine!

Technical Parameter

Model	Shearing Thickness (mm)	Shearing Width (mm)	Shearing Angle (°)	Number of Stroke (spm)	Back Gauge Stroke (mm)	Motor Power (kW)	Overall Dimension (L × W × H) (mm)
Q11-2 × 1000	2	1000	1°30'	75	350	1.5	1580 × 1450 × 1080
Q11-2 × 1300	2	1300	1°30'	75	350	1.5	1580 × 1450 × 1100
Q11-3 × 1200	3	1200	2°25'	55	350	2.2	1980 × 1500 × 1300
Q11-3 × 1300	3	1300	2°14'	55	350	3	2080 × 1550 × 1300
Q11-3 × 1500	3	1500	2°	55	350	3	2280 × 1550 × 1300
Q11-3 × 1600	3	1600	2	55	350	3	2280 × 1650 × 1300
Q11-3 × 2000	3	2000	2	25	500	5.5	3050 × 1650 × 1350
Q11-4 × 2000	4	2000	1°30'	25	500	5.5	3050 × 1900 × 1350
Q11-4 × 2500	4	2500	1°30'	25	500	5.5	3580 × 1900 × 1350
Q11-4 × 3200	4	3200	1°14'	20	500	7.5	4200 × 1960 × 1350
Q11-6.3 × 2000	6.3	2000	2°	40	500	5.5	3160 × 1760 × 1530
Q11-6 × 2500	6	2500	1°45'	40	500	7.5	3660 × 1760 × 1530
Q11-8 × 2500	8	2500	1°57'	45	500	11	3680 × 2160 × 1550
Q11-13 × 2500	13	2500	3°	30	600	15	3580 × 2300 × 2500
Q11-16 × 2500	16	2500	3°	30	700	18.5	3680 × 2600 × 2500
