Description
Hydraulic folding machine is also known as hydraulic bending machine or hydraulic press brake. It consists of right and left wall boards, oil box, working table, groove steel, etc. This machine is well appreciated for its high strength and accuracy as well as its excellent rigidity.
Features
1. With bidirectional and unidirectional positioning functions, sheet metal folding machinery can effectively eliminate the screw clearance.
2. Our hydraulic folding machine is capable of automatically or manually searching for a reference point.
3. Our sheet metal folder can avoid the end gauge device interfering with the workpiece, reducing wear and improving positioning accuracy.
4. This sheet metal folding machinery features multi-step process editing function, enabling dynamic multi-step operation and improve production efficiency.
5. Our hydraulic folding machine is designed with power failure position memory function to record the parameters, location and site protection procedures.
6. For this sheet metal folding machinery, one axis servo motor automatically controls the up and down stroke adjustment of slider, and the other axis servo motor controls back gauge.
Advantages
1. This sheet metal folder adopts steel welded structure. It uses normalizing and high frequency vibration to eliminate stress and ensure the overall accuracy.
2. It enjoys excellent rigidity as well as superb anti-distortion and anti-tilt capability.
3. This hydraulic folding machine adopts imported seals to improve its stability during operation.
4. Integrated control system is designed to reduce the piping installation.
5. Adopting mechanical block and torsion axis synchronization, our sheet metal folding machinery is accurate, reliable and economical.
6. The machine’s back gauge range and ram stroke can be automatically adjusted by the CNC system or manually operated.
7. Thickened table plate and slider allow the machine to acquire high rigidity. This ensures that the slider and table will undergo minimal deformation, and the workpiece can enjoy excellent straightness and angle consistency.
8. The upper die of our sheet metal folder is equipped with a deflection compensation mechanism.
9. The main cylinder piston of our hydraulic folding machine adopts nickel-phosphorus surface treatment, making its hardness reach HRC60 or more.
Notes
Give us the information of metal plate material, such as thickness, maximum width, and we will quote you the most suitable machine!
Technical Parameter
Type
|
3 × 2500
|
3 × 3200
|
3 × 6000
|
4 × 2500
|
4 × 3200
|
Max. Folding Length (mm)
|
2500
|
3200
|
6000
|
2500
|
3200
|
Max. Folding Thickness (mm)
|
3
|
3
|
3
|
4
|
4
|
Rotation Angle of the Bending Beam (°)
|
120
|
120
|
100
|
120
|
120
|
Max. Lift of the Upper Beam (mm)
|
110
|
110
|
50
|
110
|
110
|
Main Motor (kW)
|
4
|
4
|
7.5
|
5.5
|
5.5
|
Net. Weight (kg)
|
2750
|
3350
|
9450
|
3250
|
3950
|
Dimension (mm)
|
Length
|
3700
|
4400
|
7200
|
3750
|
4450
|
Width
|
1640
|
1640
|
1650
|
1640
|
1640
|
Height
|
1650
|
1650
|
2360
|
1650
|
1650
|
