C-Frame Press

Description

1. Our C-frame hydraulic press is extensively used for punching and straightening work.
2. It uses C-frame structure with the main structure steel welded and heat treated to improve its rigidity and stability.
3. Cartridge valves are mounted on the hydraulic system for reliable and durable performance and less hydraulic impact.
4. Independent electrical control system of this C-frame hydraulic machine significantly facilitates maintenance. All the major electric components are purchased from SIEMENS.
5. Centralized button control panel to facilitate operation.
6. Range of slider stroke, pressure and punching speed can be set according to practical needs.
7. Safety light curtains are utilized help increase safety during the punching operation.

Features

1. CE Certification
2. High performance
3. High quality
5. Easy to operate

Technical Parameter

Model		6.3	10	16	25	40	63	100	160	200	315	400	500	630	800
Normal Force (KN)		63	100	160	250	400	630	1000	1600	2000	3150	4000	5000	6300	8000
Max. Working Pressure (MPa)		8	12.5	20	16	25	25	25	25	25	25	25	25	25	25
Max. Stroke of Slide Block (mm)		250	250	400	400	400	500	600	700	700	800	800	900	900	900
Max. Opening Height (mm)		400	400	500	630	630	750	800	900	1000	1100	1250	1300	1500	1500
Depth of Throat (mm)		200	200	250	350	350	320	400	420	450	800	1500	1500	1500	1500
Speed of Slide Stroke (mm/s)	Descent				80	80	120	100	80	80	80	80	80	80	80
	Working	18-20	20-22	18-20	18-20	18-20	18-20	15-20	10-12	10-15	8-10	8-10	10-15	6-10	5-8
	Return	55	50	50	75	75	100	100	100	70	60	55	70	60	45
Size of Worktable (mm)	R-L	440	440	500	580	700	710	800	800	900	1500	2000	2500	2500	3000
	F-B	380	380	450	570	570	600	700	700	900	1500	1800	2000	2000	2400
Height of Worktable (mm)		700	700	710	710	710	810	800	800	900	400	400	400	400	400
Size of Hole (mm)					φ100	φ100	φ100
Motor Power (kW)		3	3	4	5.5	5.5	7.5	7.5	7.5	15	22	22	2 × 22	2 × 22	2 × 22
